Features

Equipped with a Siemens PLC and Touch Screen control, Panasonic or ABB motors, Banner sensors and FESTO pneumatic parts.

Reliable, quiet and clean operation.

Automatic lifting system for adjusting the height for different bottle heights.

Multiple desiccants inserting without additional change parts.

10 job settings can be stored in the system's memory.

Conveyor backlog detection.

All stainless-steel construction to meet cGMP standard.

The desiccant inserting machine can work independently or can be integrated into a bottle production line.

Custom design is available.

For canister desiccant inserting please click here DI-200A.

Desiccant size:          Length 10 - 40 mm, Width 5 - 30mm.

Bottle height:             30 - 110mm.

Bottle opening Dia.:   50 - 200mm.

Compressed air:        0.4 - 0.6Mpa.

Air consumption:       50L per minute.

Running speed:         40 - 100 bottles per minute.

Voltage:                     220V 1phase or 110V 1phase 50/60Hz.

Power:                      1.2kw.

Dimensions:              L800 * W900 * H1900mm (without a conveyor)

Weight:                      170kg.
