TotalPacks Capsule fillers are suitable for a wide range of applications, from pharmaceutical production to food supplements, vitamins and minerals, food technology, veterinary and other special use. For sales inquiries please contact us via email sales@totalpacks.com or click the button below
Features
Good-looking appearance, exquisite workmanship, ease of operation and simplicity of use.
PLC and Touch screen controls, easy to operate.
Easy to adjust the filling weight, speed selection and capsule length adjustment on the touch screen.
Stowage seat and measuring plate are designed as one unit to make measuring plate and stowage rod without deviation.
Ineligible capsule can be eliminated automatically, the medicine in the capsule can be recycled and be reused.
The dust collector, vacuum pipe and waste air pipe are installed inside the machine, easy to clean the platform.
Capable of filling capsules with powder, granules or pellets.
Change mold for different size capsules easily, simply and precisely.
Model: CFM-800A CFM-1000A CFM-1200A CFM-2500A CFM-3800A CFM-7500A
Running speed: 800ppm 1000ppm 1200ppm 2500ppm 3800ppm 7500ppm
Quantity of die holes: 6 8 9 18 27 54
Capsule size: 000#, 00L#, 00#, 0L#, 0#, 1#, 2#, 3#, 4# capsules.
Filling precision: >99%
Voltage: AC208-415V 3phase 50/60Hz.
Power: 5.5kw 5.5kw 5.5kw 6.75kw 9.5kw 10.5kw
Vacuum: 0.02-0.06Mpa
Dimensions(mm): L970×W820×H1900 L970×W820×H1900 L970×W820×H1900 L1150×W1040×H2230 L1430×W1280×H2080 L1700×W1220×H2015
Weight: 900kg 900kg 900kg 1400kg 2400kg 3400kg
